EXTERNAL CD-REWRITER
PARALLEL PORT, PC CARD AND USB

PLUG & PLAY ... Pull this spinner from its box and you're only seconds away from a new cd-rewriter for any Pentium PC. Just plug it into your parallel port, PC Card slot or USB port. Only backpack is hot pluggable on the parallel port, so there‘s never a need to restart your PC!

Model Number	Parallel Port Interface	PC Card Interface	USB Interface	Write, Rewrite, Read Speeds
190130				4x4x24
191100				4x4x24
192100				4x4x24

SHAREABLE & STURDY ... Pass it around at work. This classic design is built to last.

YOU'LL NEVER LOSE YOUR PRINTER ... Only backpack has a smart pass-through port so you never lose your printer when connected to the parallel port.

FAST & VERSATILE ... The backpack cd-rewriter is the only parallel port cd-rewriter that creates a full 650MB CD in just 20 minutes with the added versatility of PC Card and USB connections.

SOFTWARE INCLUDED ... Find all the software you need to create your own CDs right in the box.

GREAT FOR:

Publishing information on CDs
Creating audio CDs
Sharing spreadsheets, presentations and reports
Downloading Internet files
Saving and editing graphic images and photographs
Disaster recovery
Hard drive imaging

Model Number		Price
190130		$299.00
191100		$319.00
192100		$309.00

SPECIFICATIONS

Transfer Speed*	USB Type I — 1MB/s (max.) EPP/ECP — 1.2MB/s (max.) PC Card Type II — 2.5MB/s (max.)

Data Buffer	2MB

Typical Access Time	350 milliseconds 12cm disc 1/3 stroke

Supported Media	High Sierra, ISO 9660, CD-ROM XA, Photo CD, MultiRead CD-RW, CD-R and CD-audio format

Recording Media	CD-RW, CD-R

Bundled Software	Adaptec® DirectCD™ and Easy CD Creator™

Write Speeds	1X, 2X, 4X**

Rewrite Speeds	2X, 4X**

Read Speeds	24X - 1.0MB/s max. with USB Type I 1.2MB/s max. with EPP/ECP 2.5MB/s max. with PC Card Type II

Power Consumption	14 watts, universal power supply included

Line Voltage Range	100 - 240 VAC

Operating Temperature	41°F - 95°F (5°C - 35°C)

MTBF	120,000 POH @ 20% utilization

Approvals	UL, CSA, FCC class B, CE, TÜV, SEMKO

Dimensions	2 3/16"(h) x 7 1/16"(w) x 11 3/4"(l) 5.6cm (h) x 17.9cm (w) x 29.8cm (l)

Weight	4lbs, 8oz. (2067g); power supply - 8oz. (227g); parallel port cable - 5oz. (142g); PC Card and cable - 3.3oz. (95g); USB cable - 2.5oz. (69g)

Warranty	1 year

PRODUCT FEATURES

Attach to PC Card slot, USB and Parallel Port — perfect for desktop and notebook PCs
Hot Pluggable with PC Card, USB and Parallel Port — attach and detach the drive without restarting your PC under Windows™ 95^†, 98 and 2000
Rewrite CD-RW, write CD-R and read CD-ROM discs
Create your own custom CDs – both audio and data
Includes CD creation tools software for both audio and data CDs
Use CD-RW discs for up to 650MB of rewritable storage per disc
Use CD-R discs for archiving or distributing up to 650MB of data
Use CD-RW discs to update and rewrite data like a diskette
MPC 2 compliant with EPP/ECP, PC Card and USB
Device drivers for Windows™ (95¹, 98, NT 4¹ and 2000) included
Includes un-install utility to remove software drivers from Windows™
Plays both CD-ROM program and audio CDs
Can be daisy-chained with other backpack drives
Smart pass-through port allows you to print without disconnecting the drive when attached to the parallel port
Uses Micro Solutions’ patented parallel port interface technology, PC Card interface and industry standard Universal Serial Bus (USB)
Supports LPT1 - LPT3
Also available: backpack CD-ROM, hard and diskette drives

SYSTEM REQUIREMENTS

IBM compatible Pentium, or Pentium equivalent
Standard EPP/ECP parallel port or PC Card slot or USB port
Microsoft Windows™ 95^†, 98 or NT 4^† or 2000
16MB RAM min., 32MB RAM recommended
10MB free hard drive space per minute of music to be recorded

*Max. transfer speeds. Transfer speeds are dependent on the host PC.
**Writes at 2x or 1x speeds on slower computers.
†USB not supported under Windows 95 or Windows NT 4.

This excerpt is taken from msi Website
